ZS-FS06 Vertical 1kg Washing Detergent Powder Packing Machine
🎄 Designed for large-volume packing of powders into bags.
🎄 Auger filling system, filling range can be customized.
🎄 Automatic powder feeding system.
🎄 With dust bucket to ensure production cleanliness.
🎄 Can be customized into back-side/3-side/4-side packing.
Video
Share to:
Product Description:
This powder packing machine is designed for large-volume packaging. It adopts auger filling system, which is suitable for packing dry powders, such as washing powder, milk powder, turmeric powder. The machine is equipped with powder feeder, enabling it to supply powder into hopper automatically. The detergent powder packing machine can be customized according to your production need.
|
Machine Model |
ZS-FS06 | ||||
|
Voltage |
110/220V 50-60HZ |
||||
| Packaging Speed |
About 5-80 bags/minute |
||||
|
Roll Film Thickness |
0.05-0.2mm |
||||
|
Roll Film Inner Diameter |
φ75mm |
||||
|
Roll Film Outer Diameter |
Max 360mm |
||||
|
Film Materials |
POPP/CPP, POPP/VMCPP, CPP/PE, etc. |
||||
|
Measuring Method |
Electronic Scale/Screw/Measuring Cup/Four-Head Scale/Manual Feeding (optional) | ||||
| Air Pressure |
0.6-0.8Mpa |
||||
|
Max Film Width |
420mm | 520mm | 620mm | 730mm | 900mm |
| Bag Making Size | W:60-200mm L:80-330mm |
W:60-250mm L:80-350mm |
W:120-300mm L:100-400mm |
W:120-350mm L:150-480mm |
W:150-450mm |
|
Filling Range |
100-1000ml | 150-2000ml | 250-3000ml | 250-5000ml | 500-10000ml |
| Air Consumption | 350L/min | 400L/min | 450L/min | 450L/min |
500L/min |
|
Power Supply |
3KW | 3.5KW | 4KW | 4KW | 4.5KW |
| Machine Weight | 400kg | 500kg | 600kg | 700kg |
900kg |
|
Machine Size |
1430*1140*
1640mm |
1440*1140*
1740mm |
1660*1310*
2030mm |
1660*1410*
2200mm |
2220*1820* 2700mm |
Touchscreen Panel
Intuitive interface makes it convenient for parameter monitoring. The language of panel can be customized.
Auger Feeder
Can realize continuous supplying of powders, saving labor cost.
Sealing Structure
Sealing temperature can be adjusted to suit for different packaging films. It can be customized for 3-side-seal/4-side-seal/back-side-seal bags.
Dust Bucket
Can remove airborne powder particles generated during filling, sealing, or bag forming to keep the packaging area clean.
- Applicable Products: Detergent powder, bleaching powder, milk powder, baking powder, cocoa powder, etc.
- Applicable Industries: Daily chemical, food, medicine industries.
