ZS-AFCL9 Automatic Pharmaceutical Vial Filling Line

🎄 Machine output is 1800-3600BPH.
🎄 Can realize filling, stoppering, capping and labeling.
🎄 With laminar flow hood to ensure cleanliness of filling capping area.
🎄 Servo peristaltic pump system, filling range is customized.
🎄 Optional Devices: Vial rinsing machine, date coder.
🎄 Machines can be customized as your needs.

Video

Share to:

Product Description:

This pharmaceutical vial filling line is consisting of monoblock filling capping machine and labeling machine. Built with servo-driven peristaltic pumps, it has high filling precision and is suitable for packing medical liquids. The filling and capping area operates under laminar airflow, ensuring product cleanliness. The vial packaging line can be customized according to your production needs.

>Vial Filling And Capping Machine

Machine Model	ZS-AFC39
Machine Voltage	220V/110V 50-60Hz
Power	<3000W/h
Production Speed	About 30-60 bottles/min(depending on product size and filling materials)
Filling Pump	Servo Peristaltic Pumps
Filling Head Quantity	4 Heads
Filling Range	Can be customized
Filling Accuracy	±3%
Machine Size	About 233014002100mm(LWH)
Machine Weight	About 900kg
Package Size	About 253017001930mm(Main Machine) About 220012701680mm(Laminar Flow Hood)
Package Weight	About 1407kg(Main Machine)+418kg(Laminar Flow Hood)=1825kg

>Vial Labeling Machine

Machine Model	ZS-TB821
Machine Voltage	220V/110V 50-60Hz
Power	570W
Production Speed	About 40-120 bottles/min (depending on product and label size)
Labeling Accuracy	±1.0mm
Applicable Product Size	φ25-φ120mm(Round Bottles)
Label Size	(W)20-300mm*(H)20-95mm
Label Roll Inner Diameter	φ76mm
Label Roll Outer Diameter	φ300mm
Machine Size	About 204011801370mm(LWH)

❤ Notice: Parameters are for reference only and may vary depending on your products. Please contact us for more details if needed.

Touchscreen Panel

Touch screen with PLC control, it allows for easy monitoring and adjusting of machine settings. The panel can be customized into different languages.

Rotary Filling Capping System (Cam Control)

Can realize functions of filling liquids, feeding stoppers and caps, and crimping caps at one machine. The starwheel is customized based on your product size.
